INSULATE UKRAINE
RESPONSE V2
A rapid-deployed emergency replacement window system designed to restore protection, insulation, and basic livability to buildings damaged by war.
Built for humanitarian led emergency repair
Designed for rapid post-strike repair, V2 enables our local builder teams to quickly measure, cut, and install emergency replacement windows where homes and buildings have been damaged.
-
Designed to improve insulation and reduce heat loss in damaged buildings where conventional glazing is unavailable.
-
PET glazing is designed to better withstand everyday impact, debris, and post-blast damage than conventional glass.
-
If damaged, PET is designed to deform or tear rather than shatter into dangerous sharp fragments, helping reduce injury risk.
-
Designed to improve weather sealing, helping reduce drafts, rain ingress, and further exposure after window damage.
-
Designed to keep emergency window repair low-cost and scalable, making rapid replacement more feasible at large scale.
-
Built from recyclable wood and PET components that can be repaired, replaced, or recycled at end of use.
Designed for Rapid Local Installation: Built for fast, intuitive assembly by local teams, enabling neighbors to quickly restore protection in their own communities after a strike.
Product Specifications
V2 is a lightweight emergency replacement window system designed for rapid post-strike deployment by local installation teams in conflict-affected and disaster-damaged buildings. It helps restore weather protection, thermal performance, daylight, and basic occupant safety when conventional glazing is unavailable, delayed, or impractical.
The system consists of a locally cut and assembled engineered softwood frame fitted with a double-layer PET glazing configuration. Two PET sheets are fixed to the frame to create an insulating air gap, helping restore basic protection, visibility, and weather resistance after window damage.
Structural System
Frame: Engineered softwood, cut and assembled on-site
Glazing: Twin-sheet PET (Polyethylene Terephthalate)
PET Thickness: Approx. 500 microns per sheet
Fixing Method: PET secured using staples or equivalent fixings and glazing bead
Seal: Industrial-grade adhesive tape and perimeter silicone for improved sealing and insulation
Material Composition
The system is designed for rapid on-site fabrication and installation by trained local teams. Timber components are cut and assembled in the field, after which PET glazing sheets are fixed into place to form a lightweight, double-layer emergency window. Installation is designed to be straightforward, adaptable, and suitable for post-strike repair conditions.
Assembly Method
The double-layer PET design is intended to restore basic thermal insulation, weather protection, and natural daylight in damaged buildings. By helping reduce drafts, uncontrolled air infiltration, and exposure to rain or snow, the system improves immediate indoor livability when conventional glazing is unavailable or delayed.
Thermal & Environmental Performance
Unlike conventional glass, PET is shatter-resistant and does not break into dangerous sharp fragments. When damaged, it is more likely to deform or tear rather than explosively shatter, helping reduce secondary injury risk in blast-affected environments.
Impact & Safety Behavior
The system is designed for repairability and practical field maintenance. PET sheets can be replaced on-site if damaged, while the timber frame can be adapted or rebuilt as needed. Both wood and PET components are recyclable, supporting lower-cost repair and reduced material waste over time.
Serviceability & Lifecycle
Frequently Asked Questions
-
V2 is an emergency replacement window system designed for buildings with shattered or destroyed glazing in conflict-affected and disaster-affected environments. It is intended to quickly restore basic weather protection, insulation, daylight, and occupant safety when conventional glass replacement is not immediately possible.
-
The V2 system consists of a locally cut and assembled engineered softwood frame with two layers of PET glazing. The PET sheets are fixed to the frame using staples or equivalent fixings, with adhesive tape and perimeter silicone used to improve sealing and insulation.
-
V2 is installed by trained local teams who measure each opening and build the window on-site. The timber frame is cut and assembled, PET glazing is fixed to the frame, and the completed unit is then installed and sealed into the opening to restore protection after a strike.
-
V2 is designed for rapid on-site assembly and installation by trained local teams. Timber components are measured, cut, and assembled in the field, then fitted with PET glazing to create a lightweight emergency replacement window that can be installed quickly after a strike.
-
Unlike boarded-up windows, V2 helps keep homes brighter, warmer, and more protected after damage. It is designed to restore a basic level of comfort and safety rather than simply closing off the opening.
-
Yes. WindowKit V2 is designed to improve insulation and reduce drafts, helping damaged buildings retain more heat and remain more habitable in cold conditions.
-
The system is designed to provide basic weather sealing by helping reduce drafts and limit rain or snow ingress after window damage. In V2, this is achieved using perimeter sealing methods including industrial-grade adhesive tape and silicone to improve protection and insulation.
-
Unlike conventional glass, PET is designed to deform or tear when damaged rather than break into dangerous sharp fragments, helping reduce the risk of secondary injury.
-
Yes. The main materials used in V2 (PET and wood) are recyclable, helping reduce waste at end of use where appropriate recycling streams are available.
-
V2 can be used in a wide range of buildings affected by window damage, including homes, apartment blocks, schools, medical facilities, and public buildings where rapid window replacement is needed.
